Entity: STORE

Top

This entity records information about all the Stores (locations) of the Restaurant.

Attributes
ID PRIMARY KEY
Name Store name. UNIQUE identifies the Store. Cannot register two Stores with the same Name. NOT NULL UNIQUE
City_ID Lookup for the City where the Store is located. NOT NULL
Is_Active Flag attribute to indicate if the Store is still operational at location or it is closed permanently. NOT NULL
Legal_Entity_Name Legal Entity Name of the company who owns the Store. NOT NULL
Registration_Number Registration Number of the company who owns the Store.
Tax_Code Tax Code of the company who owns the Store (VAT code).
Address Store Address used for invoice creation, delivery pick-up location etc. NOT NULL
GPS_Location Store GPS location. Can be used for delivery pick-up location etc
Postal_Code Store postal code.
Phone Store phone number.
Fax Store fax number.
Email Store email.
Website Store website http address.
Logo Store logo (image, etc).
Bank_Branch Branch of the bank where the company who owns the Store has the bank account.
Bank_Code Bank code of the bank where the company who owns the Store has the bank account.
Bank_Account Bank Account of the company who owns the Store.
Comments Internal notes used for clarifications on record content. Can be seen and edited only by Store Employees.

Entity: SETTING

Top

This entity records the Settings (parameters) defined at Store level.

Attributes
ID PRIMARY KEY
Store_ID Lookup for the Store for which the Setting was defined. Each Store has a Setting record. NOT NULL UNIQUE
Language_ID Lookup for the main language used on the Store website. NOT NULL
Currency_ID Lookup for the main currency used on the Store website. NOT NULL
Average_Preparation_Time Average preparation time for an Order. Average_Preparation_Time is expressed in number of minutes. NOT NULL
Is_Busy_Mode Flag attribute to indicate if the Store is busy.
Example:
⦁ If Is_Busy_Mode attribute is set TRUE, then the estimated Order preparation time is increased from Average_Preparation_Time to Busy_Preparation_Time.
See Subject Area: ORDER - Order Process and Status, Step: Prepare Order for more information. NOT NULL
Busy_Preparation_Time Estimated preparation time for an Order when the Store is busy. Busy_Preparation_Time is expressed in number of minutes. NOT NULL
Is_Ordering_Pause Flag attribute to indicate if the Store is in ordering pause.
Example:
⦁ If Is_Ordering_Pause attribute is set TRUE, then the Customers are blocked to send new Orders. In this case the Store will not receive new Orders.
⦁ As soon as the Is_Ordering_Pause attribute is set FALSE, the Store will start to receive new Orders.
See Subject Area: ORDER - Order Process and Status, Step: Prepare Order for more information. NOT NULL
Public_Reviews Flag attribute to indicate if the Customer order reviews are public and displayed on the Store website. NOT NULL.
Example:
⦁ If Public_Reviews attribute is set TRUE then the Customer reviews are public and can be viewed by other Customers on Store website
⦁ If Public_Reviews attribute is set FALSE then the Customer reviews are private and cannot be viewed by other Customers on Store website.
See Subject Area: ORDER, Entity: ORDER_REVIEW for more information.
Comments Internal notes used for clarifications on record content. Can be seen and edited only by Store Employees

Entity: LANGUAGE

Top

Languages list

Attributes
ID PRIMARY KEY
Name Language name. NOT NULL UNIQUE
Description Language description

Entity: CURRENCY

Top

Currencies list

Attributes
ID PRIMARY KEY
Name Currency name NOT NULL UNIQUE
Description Currency description

Entity: HOUR

Top

Day hours list. This entity facilitates Store and Menu hours selection and display.

Attributes
ID PRIMARY KEY
Name Hour name NOT NULL
AM_PM Ante Meridian or Post Meridian hour. This attribute can have 'AM' or 'PM' value. NOT NULL
Description Hour description

CONSTRAINT Hour_UK UNIQUE (Name, AM_PM)).

Example

HOUR

Name AM_PM
9 AM
9 PM
3 AM
7 PM etc.

Entity: HOLIDAY_REASON

Top

List of holiday reasons. Could be legal holidays or other ad-hoc store holidays.

Attributes
ID PRIMARY KEY
Name Holiday reason (holiday name) NOT NULL UNIQUE
Description Holiday description

Entity: HOLIDAY

Top

This entity records all Holidays for each Store.

Attributes
ID PRIMARY KEY
Store_ID Lookup for the Store for which the Holiday record was defined. Each Store can have many Holiday records. NOT NULL
Holiday_Reason_ID Lookup for the Holiday reason (Holiday name) for which the Holiday record was defined. NOT NULL
Start_Date Holiday start date. NOT NULL
Start_Hour_ID Lookup for the Holiday start hour. NOT NULL
End_Date Holiday end date. NOT NULL
End_Hour_ID Lookup for the Holiday end hour. NOT NULL
Comments Internal notes used for clarifications on record content. Can be seen and edited only by Store Employees.

CONSTRAINT UK_Holiday UNIQUE (Store_ID, Holiday_Reason_ID, Start_Date). Cannot have two Holidays for the same Store, with the same Holiday Reason and starting on the same date.

Important

The Holiday hours override the Menu hours.

See Subject Area: MENU, Entity: MENU_HOUR for more information.
